Basic Info.
|
Model \ Parameter |
SEN1050A |
SEN1350A |
SEN1650A |
|
Max.material width |
1050 mm |
1350 mm |
1650 mm |
|
Max.unwind diameter |
φ800 mm |
φ800 mm |
φ800 mm |
|
Max.rewind diameter |
φ800 mm |
φ800 mm |
φ800 mm |
|
Total power |
53 kw |
58 kw |
62 kw |
|
Water heater included |
3 sets |
3 sets |
3 sets |
|
2-component glue mixer |
1 set |
1 set |
1 set |
|
G.Weight |
11000 kgs |
13000 kgs |
15000 kgs |
|
Dimension(L*W*H) |
5800*3050*3050 mm |
5800*3350*3050 mm |
5800*3650*3050 mm |
Main Feature:
Ø Accurate coating amount control and easy adjustment;
Independent servo motor drive and linear independent adjustment enable the operator to accurately control the coating amount, and the adjustment is convenient with good replicability.
Ø High Laminating Quality
The material path has been carefully laid out, especially the use of a five-roller transferring coating mechanism, three-roller laminating mechanism and servo motor taper rewinding mechanism guarantee the uniformity of lamination and rewinding.
Ø Highly User-friendly
Reasonable layout of the control panel and the use of pneumatic observation protective device make the operation of machine very convenient.
Ø Machine safety is good, stable and reliable;
As the main electrical components comply with CE safety standards, critical components are strictly handled, making the machine safe and reliable, it still can run smoothly at high speeds.
Ø Easy operation
Not only the above-mentioned perfect hardware structure, but also equipped with process method and other software support, the combination of software and hardware enable users to quickly master the use of equipment, effectively reduce the various consumption before production.
Substrate Types
And other films with the same properties as the above substrates.
|
Laminating substrates |
Thickness of substrates |
Coating substrates |
Thickness of substrates |
|
BOPP |
12-80 μm |
BOPP |
12-80 μm |
|
PETP |
8-30 μm |
PETP |
10-30 μm |
|
LDPE,LLDPE |
20-200 μm |
LDPE,LLDPE |
30-200 μm |
|
OPA |
12-18 μm |
OPA |
12-18 μm |
|
NYLON CAST |
20-80 μm |
NYLON CAST |
30-80 μm |
|
ALU(Foil) |
6.3-40 μm |
PP CAST |
60-150 μm |
|
PP CAST |
20-150 μm |
PAPER |
40-150 gsm |
|
COEX FILM |
20-200 μm |
|
|
|
PAPER |
40-150 gsm |
|
|
After Sales Service
As the ultimate manufacturing factory, we not only provide you competitive factory price, visible capital goods,but also more invisible values including:
1) In-time delivery
2) One year quality guarantee and overseas technical service
3) Competitive factory price without any third party involved
4) Tailored solutions for specific demand and requirements provided
5) Quick delivery for spare parts
6) Fast response to customer's confusions
7) Keep customers updated with the production steps
8) Strict quality control during production and do inspection before delivery
9) Instant remote technical consultation and operation guidance
10) Shipping following up until goods arrives at destination safely
OUR SERVICE COMMITMENT FS
1. Before- sale service
1) 24hours online free consultation of equipment
2) Provide the standard device and the flow chart
3) Customize tailored solution as per client's demand and requirements
4) Welcome to visit our factory at anytime
2. Service during sales:
1) Qualified raw material and components guranteed
2) Keep clients updated with the production process
3) Strict quality control during production and inspection before delivery
3. After-sale service:
1) Shipping following up until goods arrives at destination safely
2) Instant overseas technical support and operation guidance
3) Provide the tutorial videos for install and machining
4) Quick delivery for spare parts replacement
